O-Ring Cord & Rubber Strip

Viton O-ring Cord

Cost-effective with Large stock

Viton O-ring Cord

Our Viton O-ring Cord are designed with a circular cross-section to fit snugly in a variety of grooves to provide superior sealing performance. This design ensures uniform force at the connection, preventing leakage of liquids and gases and guaranteeing leak-free operation of pipes, valves and mechanical equipment.

O-ring Cord Size:

Our CBD.SEALS O-ring Cord size and mould are from 1.0mm, 1.5mm, 1.78mm, 1.8mm, 2.0mm, 2.4mm, 2.5mm, 2.62mm, 2.65mm, 3.0mm, 3.1mm, 3.5mm, 3.53mm, 3.55mm, 3.65mm, 4.0mm, 4.5mm, 5.0mm, 5.33mm, 5.5mm, 5.7mm, 6.0mm, 6.5mm, 7.0mm, 7.5mm, 8.0mm, 8.4mm, 8.5mm, 8.6mm, 9.0mm, 9.5mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm

Explore O-ring tolerance specifications

Class I (E1) – High Precision
Class 2 (E2) – Standard
Class 3 (E3) – Normal



Cross Section (in) E1 (in) E2 (in) E3 (in) Cross Section (mm) E1 (mm) E2 (mm) E3 (mm) Add to Chart
0.000 – 0.059 +/- 0.006 +/- 0.010 +/- 0.015 0.00 – 1.49 +/- 0.15 +/- 0.25 +/- 0.40
0.060 – 0.099 +/- 0.008 +/- 0.014 +/- 0.020 1.50 – 2.49 +/- 0.20 +/- 0.35 +/- 0.50
0.100 – 0.159 +/- 0.010 +/- 0.016 +/- 0.027 2.50 – 3.99 +/- 0.25 +/- 0.40 +/- 0.70
0.160 – 0.249 +/- 0.014 +/- 0.020 +/- 0.031 4.00 – 6.29 +/- 0.35 +/- 0.50 +/- 0.80
0.250 – 0.389 +/- 0.016 +/- 0.027 +/- 0.039 6.30 – 9.99 +/- 0.40 +/- 0.70 +/- 1.00
0.390 – 0.629 +/- 0.020 +/- 0.031 +/- 0.051 10.00 – 15.99 +/- 0.50 +/- 0.80 +/- 1.30
0.630 – 0.979 +/- 0.027 +/- 0.039 +/- 0.063 16.00 – 24.99 +/- 0.70 +/- 1.00 +/- 1.60
0.980 – 1.569 +/- 0.031 +/- 0.051 +/- 0.079 25.00 – 39.99 +/- 0.80 +/- 1.30 +/- 2.00
1.570 – 2.479 +/- 0.039 +/- 0.063 +/- 0.098 40.00 – 62.99 +/- 1.00 +/- 1.60 +/- 2.50
≥ 2.480 +/- 0.051 +/- 0.079 +/- 0.126 ≥ 63.00 +/- 1.30 +/- 2.00 +/- 3.20

Our CBD.SEALS O-ring Cord Advantage:

  • Wide range of applications
    Whether for automotive manufacturing, hydraulic systems, pneumatic equipment or other industrial machinery, our O-Rubber Strips meet the sealing needs of different industries. They are suitable for connections in a wide range of materials and sizes, including high temperature, high pressure and corrosive media.
  • Versatile material selection
    We offer O-ring Cord Rubber Strip in a wide range of materials to suit different applications. From Nitrile to Silicone Rubber, and from Viton to EPDM, we have an extensive lineup to meet a wide range of precision sealing requirements.
  • Durability and Reliability
    O-ring Cord Rubber Strip undergo rigorous quality control and testing to ensure that each one offers superior durability and reliability. Our O-ring Cord Rubber Strip maintain consistent performance in both extreme temperatures and harsh operating environments.
  • Easy Installation
    The simple design of our O-ring Cord Rubber Strip allows for quick and easy installation without the need for special tools. Their round cross-section and flexible nature make them easy to install in a variety of joints, greatly simplifying maintenance and replacement.
  • Cost-effective solution
    By investing in our O-ring Cord Rubber Strip, you get a cost-effective sealing solution. These rubber strips significantly reduce the risk of leakage and improve system efficiency, thereby reducing operating costs.
  • Customized services
    We offer customized O-ring Cord Rubber Strip to meet the specific needs of our customers. Whether it’s a special size, a special material or a special design, our team of engineers can work closely with you to provide a customized solution.

Enquire Now

If you are interested in our O-ring Cord Rubber Strip or need more product information and technical support, please contact us through our website. We look forward to working with you to provide you with the best quality sealing solutions.
